Description
Product Features |
|
Lifting capacity |
2800kg |
Max Lift height |
1200mm |
Minium height |
120mm |
LIifting Arm Maximum Width |
1200mm |
LIifting Arm Maximum Length |
1900mm |
The frame width |
900mm |
The frame length |
1700mm |
Lifting time |
30s(adjustable) |
Moter power |
1.5kw |
Specifications
1. It is a ideal lifting equipment for tire changing and quick service,oil change, fast repair and maintenance, automobile tires
and other lifting machine
2. Strong undercarriage support make the lift more stable and safe.
3. Mechanical safety lock engaged automatically, with manual release when lowering;
4. Screw-up pads makes easy and quick service;
5. Parachute valve equipped in hydraulic joint ensures safety in case of oil hose broken;
6. The mobile kit is perfectly combined with power unit, that makes the lift easily moved;
7. It has been proofed by dynamic test with 115% of rated capacity and static test with 150% of rated capacity;
